New Holland E235SRNLC
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 29.17 ft in (8890 mm) |
| Shipping Height Of Unit | 10.14 ft in (3090 mm) |
| Max Cutting Height | 37.05 ft in (11290 mm) |
| Max Loading Height | 27.63 ft in (8420 mm) |
| Max Reach Along Ground | 31.7 ft in (9660 mm) |
| Max Vertical Wall Digging Depth | 19.89 ft in (6060 mm) |
| Max Digging Depth | 21.99 ft in (6700 mm) |
| Boom/Stick Option (Hex) 1 | stick 2940mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 29.17 ft in (8890 mm) |
| Max Cutting Height | 38.03 ft in (11590 mm) |
| Shipping Height Of Unit | 10.14 ft in (3090 mm) |
| Max Loading Height | 28.52 ft in (8690 mm) |
| Max Reach Along Ground | 32.91 ft in (10030 mm) |
| Max Vertical Wall Digging Depth | 21.26 ft in (6480 mm) |
| Max Digging Depth | 23.3 ft in (7100 mm) |
| Boom/Stick Option (Hex) 2 | stick 3300mm |
Dimensions
| Ground Clearance | 1.5 ft in (455 mm) |
| Height To Top Of Cab | 10.14 ft in (3090 mm) |
| Width To Outside Of Tracks | 9.81 ft in (2990 mm) |
| Length Of Track On Ground | 12.64 ft in (3850 mm) |
| Tail Swing Radius | 5.52 ft in (1680 mm) |
| Removal Counterweight Clearance | 3.58 ft in (1090 mm) |
Undercarriage
| Track Gauge | 7.85 ft in (2390 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.3 mph (5.3 km/h) |
| Number Of Carrier Rollers Per Side | 2 |
| Number Of Track Rollers Per Side | 9 |
| Ground Pressure | 6.97 psi (48 kPa) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2251 |
| Engine Model | 6D34-TLU2F |
| Net Power | 158 hp (117.9 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 357.7 cu in (5.9 L) |
| Aspiration | turbocharged, intercooler |
Operational
| Operating Weight | 52690.5 lb (23900 kg) |
| Fuel Capacity | 76.7 gal (290 L) |
| Cooling System Fluid Capacity | 5.1 gal (19 L) |
| Hydraulic System Fluid Capacity | 60.8 gal (230 L) |
| Engine Oil Capacity | 6.4 gal (24 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2 gal (7.5 L) |
| Alternator Supplied Amperage | 35 amps |
| Hydraulic Pump Flow Capacity | 111 gal/min (420 L/min) |
Swing Mechanism
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 0.9 yd3 (0.7 m3) |
| Minimum Bucket Capacity | 0.7 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 1.3 yd3 (1 m3) |
