New Holland 135SRL
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 24.51 ft in (7470 mm) |
| Shipping Height Of Unit | 9.22 ft in (2810 mm) |
| Max Cutting Height | 28.97 ft in (8830 mm) |
| Max Loading Height | 20.35 ft in (6200 mm) |
| Max Reach Along Ground | 26.94 ft in (8210 mm) |
| Max Vertical Wall Digging Depth | 16.28 ft in (4960 mm) |
| Max Digging Depth | 18.05 ft in (5500 mm) |
| Boom/Stick Option (Hex) 1 | stick 2450mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 24.51 ft in (7470 mm) |
| Max Cutting Height | 29.07 ft in (8860 mm) |
| Shipping Height Of Unit | 9.22 ft in (2810 mm) |
| Max Loading Height | 21.13 ft in (6440 mm) |
| Max Reach Along Ground | 28.38 ft in (8650 mm) |
| Max Vertical Wall Digging Depth | 17.23 ft in (5250 mm) |
| Max Digging Depth | 19.72 ft in (6010 mm) |
| Boom/Stick Option (Hex) 2 | stick 2950mm |
Dimensions
| Ground Clearance | 1.5 ft in (455 mm) |
| Height To Top Of Cab | 8.99 ft in (2740 mm) |
| Width To Outside Of Tracks | 8.17 ft in (2490 mm) |
| Length Of Track On Ground | 9.96 ft in (3035 mm) |
| Tail Swing Radius | 4.68 ft in (1425 mm) |
| Removal Counterweight Clearance | 2.99 ft in (910 mm) |
Undercarriage
| Shoe Size | 19.69 in (500 mm) |
| Ground Pressure | 5.95 psi (41 kPa) |
| Max Travel Speed | 3.17 mph (5.1 km/h) |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Track Rollers Per Side | 6 |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | - 4BG1TA |
| Net Power | 85 hp (63.4 kw) |
| Power Measured @ | 2050 rpm |
| Displacement | 264.2 cu in (4.4 L) |
| Aspiration | Turbo |
Operational
| Operating Weight | 32408 lb (14700 kg) |
| Fuel Capacity | 44.4 gal (168 L) |
| Cooling System Fluid Capacity | 4.8 gal (18 L) |
| Hydraulic System Fluid Capacity | 37 gal (140 L) |
| Engine Oil Capacity | 3.5 gal (13 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.5 gal (1.7 L) |
| Alternator Supplied Amperage | 30 amps |
| Hydraulic System Relief Valve Pressure | 5468 psi (37700 kPa) |
| Hydraulic Pump Flow Capacity | 62.4 gal/min (236 L/min) |
Swing Mechanism
| Swing Speed | 11.7 rpm |
Buckets
| Reference Bucket Capacity | 0.6 yd3 (0.5 m3) |
| Minimum Bucket Capacity | 0.6 yd3 (0.5 m3) |
| Maximum Bucket Capacity | 1 yd3 (0.7 m3) |
