LiuGong 220LC
Browse All LiuGong or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 31.24 ft in (9520 mm) |
| Max Loading Height | 22.05 ft in (6720 mm) |
| Max Reach Along Ground | 32.22 ft in (9820 mm) |
| Max Digging Depth | 20.84 ft in (6350 mm) |
| Boom/Stick Option (Hex) 1 | standard |
Dimensions
| Ground Clearance | 1.45 ft in (440 mm) |
| Width To Outside Of Tracks | 9.81 ft in (2990 mm) |
| Length Of Track On Ground | 8.99 ft in (2740 mm) |
| Tail Swing Radius | 14.62 ft in (4456 mm) |
Undercarriage
| Shoe Size | 23.63 in (600 mm) |
Engine
| Engine Make | 2347 |
| Gross Power | 144.9 hp (108 kw) |
Operational
| Operating Weight | 45635.7 lb (20700 kg) |
| Hydraulic System Relief Valve Pressure | 4264.2 psi (29400 kPa) |
| Hydraulic Pump Flow Capacity | 109.4 gal/min (414 L/min) |
