Link-Belt 210LX Long Front
Browse All Link-Belt or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 40.92 ft in (12470 mm) |
| Shipping Height Of Unit | 9.85 ft in (3000 mm) |
| Max Cutting Height | 42.56 ft in (12970 mm) |
| Max Loading Height | 35.21 ft in (10730 mm) |
| Max Reach Along Ground | 50.83 ft in (15490 mm) |
| Max Vertical Wall Digging Depth | 33.7 ft in (10270 mm) |
| Max Digging Depth | 39.38 ft in (12000 mm) |
| Boom/Stick Option (Hex) 1 | Boom 28'7" (8700mm) / Stick 21'0" (6400mm) |
Dimensions
| Ground Clearance | 1.51 ft in (460 mm) |
| Height To Top Of Cab | 9.45 ft in (2880 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Length Of Track On Ground | 12.01 ft in (3660 mm) |
| Tail Swing Radius | 8.93 ft in (2720 mm) |
| Removal Counterweight Clearance | 3.42 ft in (1040 mm) |
Undercarriage
| Track Gauge | 7.85 ft in (2390 mm) |
| Shoe Size | 31.5 in (800 mm) |
| Number Of Shoes Per Side | 49 |
| Max Travel Speed | 3.4 mph (5.48 km/h) |
| Number Of Track Rollers Per Side | 8 |
| Ground Pressure | 4.93 psi (34 kPa) |
| Number Of Carrier Rollers Per Side | 2 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | BB-6BG1T |
| Net Power | 138 hp (103 kw) |
| Power Measured @ | 1950 rpm |
| Max Torque | 392 lb ft (531.5 Nm) |
| Displacement | 396 cu in (6.5 L) |
| Aspiration | Turbocharged |
| Torque Measured @ | 1600 rpm |
Operational
| Operating Weight | 47600 lb (21591 kg) |
| Fuel Capacity | 89.9 gal (340 L) |
| Cooling System Fluid Capacity | 7.2 gal (27 L) |
| Hydraulic System Fluid Capacity | 54.5 gal (206 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 6.4 gal (24 L) |
| Swing Drive Fluid Capacity | 1.2 gal (4.5 L) |
| Alternator Supplied Amperage | 40 amps |
| Hydraulic System Relief Valve Pressure | 4970 psi (34267 kPa) |
| Hydraulic Pump Flow Capacity | 106.2 gal/min (402.1 L/min) |
Swing Mechanism
| Swing Speed | 11.9 rpm |
| Swing Torque | 38500 lb ft (52199 Nm) |
Buckets
| Reference Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Minimum Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 0.9 yd3 (0.7 m3) |
