Steinbock Boss C 90
Browse All Steinbock Boss or Forklift Models
Contents:
Dimensions
| Length To Fork Face | 12.83 ft in (3910 mm) |
| Overall Width | 7.5 ft in (2285 mm) |
| Overall Height - Mast Lowered | 9.49 ft in (2890 mm) |
| Wheelbase | 8.5 ft in (2590 mm) |
| Height To Top Of Overhead Guard | 8.7 ft in (2650 mm) |
| Max Fork Height | 11.49 ft in (3500 mm) |
| Turning Radius | 12.42 ft in (3785 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Lift Speed | 78.75 ft/min (24 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 19841.61 lb (9000 kg) |
| Lower Speed | 88.59 ft/min (27 m/min) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2351 |
| Engine Model | 1006.6 |
| Power | 132.8 hp (99 kw) |
| Power Measured @ | 2250 rpm |
| Displacement | 366.2 cu in (6 L) |
| Fuel Type | diesel |
Operational
| Operating Weight | 27778.3 lb (12600 kg) |
| Tire Type | pneumatic |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 20.1 mph (32.3 km/h) |
