Noblelift FE4F16
Contents:
Dimensions
| Length To Fork Face | 6.6 ft in (2010 mm) |
| Overall Width | 3.52 ft in (1070 mm) |
| Overall Height - Mast Lowered | 6.55 ft in (1995 mm) |
| Wheelbase | 4.11 ft in (1250 mm) |
| Ground Clearance | 2.37 in (60 mm) |
| Height To Top Of Overhead Guard | 6.93 ft in (2110 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 6.24 ft in (1900 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Max Fork Spread | 36.23 in (920 mm) |
| Lower Speed | 82.68 ft/min (25.2 m/min) |
| Load Center | 19.69 in (500 mm) |
| Load Capacity | 3527.4 lb (1600 kg) |
| Lift Speed | 72.84 ft/min (22.2 m/min) |
Engine
| Power | 6.8 hp (5 kw) |
| Fuel Type | electric |
Operational
| Operating Weight | 6627.1 lb (3006 kg) |
| Tire Type | front 6.50-10-10PR rear 5.00-8-8PR |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 8.7 mph (14 km/h) |
