Noblelift CPCD50
Contents:
Dimensions
| Length To Fork Face | 11.75 ft in (3580 mm) |
| Overall Width | 6.27 ft in (1910 mm) |
| Overall Height - Mast Lowered | 9.06 ft in (2760 mm) |
| Wheelbase | 7.55 ft in (2300 mm) |
| Ground Clearance | 5.91 in (150 mm) |
| Height To Top Of Overhead Guard | 7.98 ft in (2432 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 10.83 ft in (3300 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Load Capacity | 11023.12 lb (5000 kg) |
| Load Center | 23.63 in (600 mm) |
| Lift Speed | 63 ft/min (19.2 m/min) |
Engine
| Engine Model | LR4105G3 |
| Power | 78.9 hp (58.8 kw) |
| Torque | 183 lb ft (248 Nm) |
| Displacement | 264.3 cu in (4.4 L) |
| Fuel Type | diesel |
Operational
| Operating Weight | 17196.1 lb (7800 kg) |
| Tire Type | 8.25-15-14PR |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 13.7 mph (22 km/h) |
