Komatsu FG45BCS-8
Contents:
Dimensions
| Length To Fork Face | 8.31 ft in (2530 mm) |
| Overall Width | 4.5 ft in (1370 mm) |
| Overall Height - Mast Lowered | 7.91 ft in (2410 mm) |
| Wheelbase | 5.25 ft in (1600 mm) |
| Ground Clearance | 4.93 in (125 mm) |
| Height To Top Of Overhead Guard | 6.98 ft in (2125 mm) |
| Max Fork Height | 10.83 ft in (3300 mm) |
| Right Angle Stack | 8.81 ft in (2685 mm) |
| Turning Radius | 7.32 ft in (2230 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 6 degrees |
| Number Of Mast Sections | 2 |
| Lower Speed | 95 ft/min (28.96 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 10000 lb (4535.93 kg) |
| Lift Speed | 93 ft/min (28.35 m/min) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 0 |
| Engine Model | TB45E |
| Power | 95 hp (70.9 kw) |
| Torque | 203 lb ft (275.3 Nm) |
| Power Measured @ | 2400 rpm |
| Displacement | 275 cu in (4.6 L) |
| Torque Measured @ | 1600 rpm |
| Fuel Type | LPG |
Operational
| Operating Weight | 15070 lb (6835.7 kg) |
| Tire Type | Cushion |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 9.6 mph (15.5 km/h) |
