Hyundai 1200-7
Contents:
Dimensions
| Length To Fork Face | 14.21 ft in (4330 mm) |
| Overall Width | 8.04 ft in (2450 mm) |
| Overall Height - Mast Lowered | 10.34 ft in (3150 mm) |
| Wheelbase | 9.52 ft in (2900 mm) |
| Ground Clearance | 10.63 in (270 mm) |
| Height To Top Of Overhead Guard | 10.24 ft in (3120 mm) |
| Max Fork Height | 10.85 ft in (3305 mm) |
| Turning Radius | 13.39 ft in (4080 mm) |
Mast
| Mast Tip Forward | 15 degrees |
| Mast Tip Rear | 12 degrees |
| Lower Speed | 100.4 ft/min (30.6 m/min) |
| Load Capacity | 26455.48 lb (12000 kg) |
| Load Center | 23.63 in (600 mm) |
| Lift Speed | 84.65 ft/min (25.8 m/min) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | QSB5.9-C |
| Power | 154.9 hp (115.5 kw) |
| Fuel Type | Diesel |
Operational
| Operating Weight | 35937.6 lb (16301 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 21.7 mph (34.9 km/h) |
