Hyster H40FT LP
Contents:
Dimensions
| Length To Fork Face | 8.16 ft in (2486 mm) |
| Overall Width | 3.8 ft in (1157 mm) |
| Overall Height - Mast Lowered | 7.12 ft in (2170 mm) |
| Wheelbase | 5.33 ft in (1623 mm) |
| Ground Clearance | 5.2 in (132 mm) |
| Height To Top Of Overhead Guard | 7.09 ft in (2160 mm) |
| Max Fork Height | 10.81 ft in (3292 mm) |
| Turning Radius | 7.06 ft in (2149 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Max Fork Spread | 43.27 in (1099 mm) |
| Lower Speed | 83 ft/min (25.3 m/min) |
| Load Center | 24.02 in (610 mm) |
| Load Capacity | 4001.39 lb (1815 kg) |
| Lift Speed | 111 ft/min (33.84 m/min) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2357 |
| Engine Model | FE |
| Power | 40 hp (29.9 kw) |
| Torque | 91 lb ft (123.4 Nm) |
| Displacement | 122.1 cu in (2 L) |
| Torque Measured @ | 1800 rpm |
| Fuel Type | LP |
Operational
| Operating Weight | 7985.2 lb (3622 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 7 mph (11.2 km/h) |
