Hercu 80D
Contents:
Dimensions
| Length To Fork Face | 12.8 ft in (3900 mm) |
| Overall Width | 7.67 ft in (2337 mm) |
| Overall Height - Mast Lowered | 8.8 ft in (2680 mm) |
| Wheelbase | 8.37 ft in (2550 mm) |
| Ground Clearance | 7.88 in (200 mm) |
| Height To Top Of Overhead Guard | 7.58 ft in (2310 mm) |
| Max Fork Height | 10.83 ft in (3300 mm) |
| Turning Radius | 12.8 ft in (3900 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Number Of Mast Sections | 2 |
| Lower Speed | 59.06 ft/min (18 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 17636.98 lb (8000 kg) |
| Lift Speed | 68.9 ft/min (21 m/min) |
Engine
| Engine Make | 2388 |
| Engine Model | 8065 E |
| Power | 108.7 hp (81 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 366.2 cu in (6 L) |
| Fuel Type | diesel |
Operational
| Operating Weight | 22266.7 lb (10100 kg) |
| Tire Type | pneumatic |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.5 mph (20 km/h) |
