HeLi CPD10E
Contents:
Dimensions
| Overall Width | 3.52 ft in (1070 mm) |
| Overall Height - Mast Lowered | 6.55 ft in (1995 mm) |
| Wheelbase | 4.11 ft in (1250 mm) |
| Ground Clearance | 4.14 in (105 mm) |
| Height To Top Of Overhead Guard | 6.89 ft in (2100 mm) |
| Max Fork Height | 13.23 ft in (4030 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Load Center | 19.69 in (500 mm) |
| Max Fork Spread | 37.41 in (950 mm) |
| Load Capacity | 2204.63 lb (1000 kg) |
| Lift Speed | 2.37 ft/min (0.72 m/min) |
| Lower Speed | 59.06 ft/min (18 m/min) |
Engine
| Power | 6.8 hp (5 kw) |
| Fuel Type | electric |
Operational
| Operating Weight | 5732.1 lb (2600 kg) |
| Tire Type | front 6.50-10-10PR rear 5.00-8-8PR |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 8.4 mph (13.5 km/h) |
