Cukurova CF25FX
Contents:
Dimensions
| Length To Fork Face | 8.21 ft in (2500 mm) |
| Overall Width | 4.04 ft in (1230 mm) |
| Overall Height - Mast Lowered | 7.47 ft in (2275 mm) |
| Wheelbase | 5.29 ft in (1610 mm) |
| Ground Clearance | 3.94 in (100 mm) |
| Height To Top Of Overhead Guard | 6.94 ft in (2115 mm) |
| Max Fork Height | 10.75 ft in (3275 mm) |
| Right Angle Stack | 12.78 ft in (3895 mm) |
| Turning Radius | 7.06 ft in (2150 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Max Fork Spread | 42.45 in (1078 mm) |
| Lower Speed | 88.59 ft/min (27 m/min) |
| Load Center | 19.69 in (500 mm) |
| Load Capacity | 5511.56 lb (2500 kg) |
| Lift Speed | 88.59 ft/min (27 m/min) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 404C-22 |
| Power | 50 hp (37.3 kw) |
| Torque | 105.5 lb ft (143 Nm) |
| Power Measured @ | 2800 rpm |
| Displacement | 135.3 cu in (2.3 L) |
| Torque Measured @ | 1800 rpm |
| Fuel Type | Diesel |
Operational
| Operating Weight | 8443.8 lb (3830 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 13.1 mph (21 km/h) |
