Clark Michigan ECX20
Browse All Clark Michigan or Forklift Models
Contents:
Dimensions
| Length To Fork Face | 6.91 ft in (2104 mm) |
| Overall Width | 3.49 ft in (1063 mm) |
| Overall Height - Mast Lowered | 7.34 ft in (2235 mm) |
| Wheelbase | 4.42 ft in (1346 mm) |
| Ground Clearance | 2.8 in (71 mm) |
| Height To Top Of Overhead Guard | 7.32 ft in (2229 mm) |
| Max Fork Height | 15.75 ft in (4800 mm) |
| Right Angle Stack | 7.24 ft in (2204 mm) |
| Turning Radius | 5.85 ft in (1783 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 5 degrees |
| Number Of Mast Sections | 3 |
| Lower Speed | 88 ft/min (26.83 m/min) |
| Max Fork Spread | 35.04 in (890 mm) |
| Load Center | 19.69 in (500 mm) |
| Load Capacity | 4409.25 lb (2000 kg) |
| Lift Speed | 59 ft/min (17.99 m/min) |
Engine
| Fuel Type | Electric Motor 36V |
Operational
| Operating Weight | 9348 lb (4240.2 kg) |
| Tire Type | Cushion Electric Compound |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 8.9 mph (14.2 km/h) |
