Case IH RMX370 28ft
Contents:
Dimensions
| Overall Length | 23.25 in (7086.6 mm) |
| Transport Width | 18 ft in (5486.4 mm) |
| Transport Height | 11.92 ft in (3633.22 mm) |
| Operating Speed | 7 mph (11.27 km/h) |
| Pto Power Required Per Width Ft. | 8.6 hp (6.42 kw) |
| Wing Tires | 11L x 15 8PR |
| Main Frame Tires | 12.5L x 15 FI |
| Working Width Spacing #1 Min | 28.08 ft in (8558.79 mm) |
| Max Weight | 18175 lb (8244.05 kg) |
| Min Weight | 13306 lb (6035.51 kg) |
Disc System
| Spacing #1 | 9 in (228.6 mm) |
| Depth Control | Single Point Hydraulic |
| Weight Per Blade Spacing #1 | 190 lb (86.2 kg) |
| Max Operating Depth | 6 in (152.4 mm) |
Gangs
| Gang Mounts | Rigid or C-Spring Cushion |
| Gang Arbor Bolts | 1.5 in (38.1 mm) |
| Gang Spool Type | Nodular Iron Spool |
| Gang Spool Diameter | 6 in (152.4 mm) |
| Front Disk Angle | 18 degrees |
| Rear Disk Angle | 18 degrees |
| Bearing Type | Regreasable Triple Lip, Heavy Steel Bearing, Self-aligning Flange Style |
| Scrapers | 4 in. Heavy-duty Spring Steel |
