New Holland DC85 WT
Browse All New Holland or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 13.69 ft in (4171 mm) |
| Height To Top Of Cab | 9.15 ft in (2788 mm) |
| Length Of Track On Ground | 7.42 ft in (2260 mm) |
| Ground Clearance | 1.25 ft in (379 mm) |
| Length W/O Blade | 10.35 ft in (3153 mm) |
Undercarriage
| Track Gauge | 5.84 ft in (1780 mm) |
| Standard Shoe Size | 24.02 in (610 mm) |
| Ground Pressure | 4.62 psi (31.79 kPa) |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Shoes Per Side | 39 |
| Number Of Track Rollers Per Side | 6 |
Engine
| Number Of Cylinders | 4 |
| Engine Make | New Holland |
| Engine Model | 445T/M2 |
| Gross Power | 89 hp (66.4 kw) |
| Net Power | 84 hp (62.7 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 295 lb ft (400 Nm) |
| Displacement | 275 cu in (4.6 L) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 19700.6 lb (8936 kg) |
| Fuel Capacity | 50.1 gal (189.3 L) |
| Cooling System Fluid Capacity | 5 gal (18.9 L) |
| Final Drives Fluid Capacity | 3.8 gal (14.2 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
Hydraulic System
| Pump Flow Capacity | 20.3 gal/min (76.8 L/min) |
