Komatsu D40A-5
Browse All Komatsu or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 14.69 ft in (4475 mm) |
| Width Over Tracks | 7.09 ft in (2160 mm) |
| Height To Top Of Cab | 9.17 ft in (2795 mm) |
| Length Of Track On Ground | 7.34 ft in (2235 mm) |
| Ground Clearance | 1.19 ft in (360 mm) |
| Length W/O Blade | 11.19 ft in (3410 mm) |
Undercarriage
| Track Gauge | 5.78 ft in (1760 mm) |
| Standard Shoe Size | 15.75 in (400 mm) |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Track Rollers Per Side | 6 |
| Track Pitch | 6.89 in (175 mm) |
| Number Of Shoes Per Side | 39 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | 6D105-1 |
| Gross Power | 95 hp (70.9 kw) |
| Power Measured @ | 2350 rpm |
| Displacement | 396.7 cu in (6.5 L) |
Operational
| Operating Weight | 23369 lb (10600 kg) |
Transmission
| Transmission Type | DD |
| Number Of Forward Gears | 5 |
| Number Of Reverse Gears | 4 |
Standard Blade
| Width | 9 ft in (2720 mm) |
| Height | 35.9 in (910 mm) |
