Komatsu D37A-5
Browse All Komatsu or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 12.96 ft in (3950 mm) |
| Width Over Tracks | 6.07 ft in (1850 mm) |
| Height To Top Of Cab | 8.91 ft in (2715 mm) |
| Length Of Track On Ground | 7.17 ft in (2185 mm) |
| Ground Clearance | 1.04 ft in (315 mm) |
Undercarriage
| Track Gauge | 4.76 ft in (1450 mm) |
| Standard Shoe Size | 15.75 in (400 mm) |
| Number Of Shoes Per Side | 41 |
| Number Of Track Rollers Per Side | 6 |
| Track Pitch | 6.07 in (154 mm) |
| Number Of Carrier Rollers Per Side | 1 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | 6D95L-1 |
| Gross Power | 81 hp (60.5 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 298.5 cu in (4.9 L) |
Operational
| Operating Weight | 14352.1 lb (6510 kg) |
Transmission
| Transmission Type | DPS |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
Standard Blade
| Width | 8 ft in (2415 mm) |
| Height | 37.1 in (940 mm) |
