John Deere 350D
Browse All John Deere or Crawler Tractor Models
Contents:
Dimensions
| Width Over Tracks | 6.67 ft in (2033.02 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2240 |
| Engine Model | 300 Series |
| Net Power | 48 hp (35.8 kw) |
| Power Measured @ | 2500 rpm |
| Max Torque | 126 lb ft (170.9 Nm) |
| Displacement | 179 cu in (3 L) |
| Torque Measured @ | 1300 rpm |
| Aspiration | Naturally aspirated |
Operational
| Operating Weight | 10700 lb (4853.5 kg) |
| Fuel Capacity | 22 gal (83 L) |
| Cooling System Fluid Capacity | 3.3 gal (12.3 L) |
| Engine Oil Capacity | 2.3 gal (8.5 L) |
| Hydraulic Fluid Capacity | 6.4 gal (24.5 L) |
| Final Drives Fluid Capacity | 10 gal (38 L) |
| Operating Voltage | 12 V |
Transmission
| Transmission Type | Collar shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
Hydraulic System
| Pump Type | Open-center |
| Relief Valve Pressure | 2250 psi (15515 kPa) |
| Pump Flow Capacity | 14 gal/min (53 L/min) |
