Dressta TD-9R
Browse All Dressta or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 14.7 ft in (4480 mm) |
| Width Over Tracks | 6.65 ft in (2026 mm) |
| Height To Top Of Cab | 8.93 ft in (2720 mm) |
| Length Of Track On Ground | 7.17 ft in (2185 mm) |
| Ground Clearance | 1.25 ft in (381 mm) |
| Length W/O Blade | 10.01 ft in (3050 mm) |
Undercarriage
| Track Gauge | 5.17 ft in (1575 mm) |
| Standard Shoe Size | 18 in (457 mm) |
| Number Of Shoes Per Side | 39 |
| Ground Pressure | 6.91 psi (47.65 kPa) |
| Ground Contact Area | 3096 in2 (2 m2) |
| Number Of Track Rollers Per Side | 6 |
Engine
| Engine Make | Cummins |
| Engine Model | QSB3.3 |
| Gross Power | 99 hp (73.9 kw) |
| Net Power | 93 hp (69.4 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 306 lb ft (414.9 Nm) |
| Displacement | 201.4 cu in (3.3 L) |
| Torque Measured @ | 1600 rpm |
Operational
| Operating Weight | 20745.5 lb (9410 kg) |
| Fuel Capacity | 45 gal (170 L) |
| Cooling System Fluid Capacity | 4.1 gal (15.2 L) |
| Engine Oil Capacity | 1.9 gal (7 L) |
| Hydraulic Fluid Capacity | 17.2 gal (65 L) |
| Final Drives Fluid Capacity | 4 gal (15.1 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 120 amps |
Transmission
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 5.5 mph (8.9 km/h) |
| Max Speed - Reverse | 6.5 mph (10.5 km/h) |
Hydraulic System
| Relief Valve Pressure | 2250 psi (15513.2 kPa) |
| Pump Flow Capacity | 18.4 gal/min (69.6 L/min) |
