| Track Gauge | 92 in (2336.81 mm) |
| Machine Height - Grouser Tip - Exhaust Stack | 129.7 in (3294.38 mm) |
| Length - Basic Tractor - With Striker Bars With Two Counterweights* | 206.4 in (5242.57 mm) |
| Width - Tractor - Over Trunnions | 130.4 in (3312.16 mm) |
| Height - Top Of Roof-Mounted Precleaner | 145.2 in (3688.08 mm) |
| Note | *With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in. |
| Height - Grouser | 3.1 in (78.74 mm) |
| Machine Height - Grouser Tip - Length Of Track On Ground | 126.2 in (3205.48 mm) |
| Without Trunnions - Standard Shoe Width | 130 in (3302 mm) |
| Machine Height - Grouser Tip - Erops (Top Of Railing) | 140.4 in (3566.16 mm) |
| Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser* | 183 in (4648.2 mm) |
| Machine Height - Grouser Tip - Ground Clearance | 24.1 in (612.14 mm) |
| Track Gauge | 82 in (2082.81 mm) |
| Width - Tractor - Over Trunnions | 120.4 in (3058.16 mm) |
| Note | *With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in. |
| Height - Grouser | 3.1 in (78.74 mm) |
| Height - Top Of Roof-Mounted Precleaner | 145.2 in (3688.08 mm) |
| Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser* | 183 in (4648.2 mm) |
| Length - Basic Tractor - With Striker Bars With Two Counterweights* | 206.4 in (5242.57 mm) |
| Machine Height - Grouser Tip - Erops (Top Of Railing) | 140.7 in (3573.78 mm) |
| Machine Height - Grouser Tip - Exhaust Stack | 136.31 in (3462.02 mm) |
| Machine Height - Grouser Tip - Ground Clearance | 23.8 in (604.52 mm) |
| Machine Height - Grouser Tip - Length Of Track On Ground | 128.31 in (3258.82 mm) |
| Without Trunnions - Standard Shoe Width | 106 in (2692.4 mm) |
| Track Gauge | 82 in (2082.81 mm) |
| Length - Basic Tractor - With Striker Bars With Two Counterweights* | 206.4 in (5242.57 mm) |
| Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser* | 183 in (4648.2 mm) |
| Height - Top Of Roof-Mounted Precleaner | 145.2 in (3688.08 mm) |
| Height - Grouser | 3.1 in (78.74 mm) |
| Machine Height - Grouser Tip - Ground Clearance | 24.1 in (612.14 mm) |
| Without Trunnions - Standard Shoe Width | 106 in (2692.4 mm) |
| Note | *With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in. |
| Machine Height - Grouser Tip - Length Of Track On Ground | 126.2 in (3205.48 mm) |
| Machine Height - Grouser Tip - Erops (Top Of Railing) | 140.4 in (3566.16 mm) |
| Width - Tractor - Over Trunnions | 120.4 in (3058.16 mm) |
| Machine Height - Grouser Tip - Exhaust Stack | 136.7 in (3472.18 mm) |
| Number Of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | C15 ACERT |
| Gross Power | 347 hp (258.8 kw) |
| Net Power | 310 hp (231 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 928 cu in (15.3 L) |
| Bore | 5.4 in (137.2 mm) |
| Stroke | 6.8 in (171.5 mm) |
| Emissions | Tier 4 Final/Stage IV/Korea Tier 4 |
| Engine Model | Cat C15 ACERT |
| Flywheel Power | 335 hp (249.9 kw) |
| Note (1) | All non road Tier 4 Interim and Final, Stage IIIB and IV, and Korea Tier 4 diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations. |
| Note (2) | Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241. |
| Note (3) | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.5 kg of refrigerant which has a CO2 equivalent of 3.575 metric tonnes. |
| Rpm | 1850 rpm |
| Net Power - 1,900 Rpm - Iso 9249/Sae J1349 | 312 hp (232.7 kw) |
| Net Power - 1,900 Rpm - Iso 9249/Sae J1349 (Din) | 317 hp (236.4 kw) |
| Net Power - Maximum - Iso 9249/Sae J1349 At 1,700 Rpm | 335 hp (249.9 kw) |
| Net Power - Maximum - Iso 9249/Sae J1349 Din At 1,700 Rpm | 343 hp (255.8 kw) |
