John Deere 855
Browse All John Deere or Crawler Loader Models
Contents:
Dimensions
| Width To Outside Of Tracks | 12.67 ft in (3861.82 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 500 Series |
| Net Power | 200 hp (149.2 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 730 lb ft (989.8 Nm) |
| Aspiration | Turbocharged and aftercooler |
| Torque Measured @ | 1300 rpm |
| Displacement | 619 cu in (10.2 L) |
Operational
| Operating Weight | 49600 lb (22498.2 kg) |
| Fuel Capacity | 88.3 gal (334.3 L) |
| Cooling System Fluid Capacity | 10.5 gal (39.8 L) |
| Final Drive Fluid Capacity - Each | 6.3 gal (23.7 L) |
| Hydraulic System Fluid Capacity | 40 gal (151.5 L) |
Hydraulic
| Pump Flow Capacity | 58.5 gal/min (221.5 L/min) |
| Relief Valve Pressure | 2000 psi (13789.6 kPa) |
| Raise Time | 6.7 sec |
| Dump Time | 1.5 sec |
| Lower Time | 3.7 sec |
