Kobelco CK1100G-2
Browse All Kobelco or Crawler Crane Models
Contents:
Engine
| Starter | 6.8 hp (5 kw) |
| Emission Tier Level | Tire 4 Final |
| Fuel Filter | Replaceable element |
| Fuel Tank | 105.7 gal (400 L) |
| Number Of Cylinders | 6 |
| Engine Model | J08E-VV |
| Gross Power | 285 hp (212.6 kw) |
| Air Cleaner | Dry type with replaceable paper element |
| Power Measured @ | 2100 rpm |
| Displacement | 469 cu in (7.7 L) |
| Max Torque | 750.2 lb ft (1017 Nm) |
| Torque Measured @ | 1600 rpm |
| Bore | 4.5 in (112 mm) |
| Stroke | 5.2 in (130 mm) |
| Alternator | 90 amps |
Undercarriage
| Ground Pressure | 12.9 psi (89 kPa) |
Boom
| Boom Base Section | 19.6 ft in (6 m) |
| Boom Tip Section | 22.7 ft in (7 m) |
| Jib Tip Section | 16.5 ft in (5 m) |
| Jib Base Section | 15.8 ft in (4.8 m) |
| Basic Jib Length | 29.9 ft in (9.1 m) |
| Boom Length | 40 ft in (12192 mm) |
Dimensions
| Gradeability | 40 % |
| Overall Width | 17.2 ft in (5242.6 mm) |
| Center To Center – Idler To Sprocket | 17.1 ft in (5212.1 mm) |
| Shoe Width | 36 ft in (10972.8 mm) |
| Overall Length Of Crawler | 20.7 ft in (6309.4 mm) |
| Ground Clearance | 15 ft in (4572 mm) |
| Counterweight Clearance | 3.8 ft in (1158.3 mm) |
