Salford CX8080
Contents:
Dimensions
| Overall Length | 29.76 ft in (9070 mm) |
| Width Over Tires | 12.14 ft in (3700 mm) |
| Height To Top Of Isomount Cab | 12.87 ft in (3920 mm) |
Engine
| Engine Make | 2358 |
| Engine Model | Cursor 9 |
| Power | 326 hp (243.1 kw) |
| Power Boost Power | 364 hp (271.5 kw) |
| Power Measured @ | 2100 rpm |
Operational
| Operating Weight W/O Attachment | 29806.5 lb (13520 kg) |
| Fuel Capacity | 264.2 gal (1000 L) |
| Transmission Type | hydrostatic |
| Number Of Gears | 4 |
Threshing
| Rotor Diameter | 29.6 in (750 mm) |
| Rotor Length | 61.5 in (1560 mm) |
| Rotor Speed - Low | 305 rpm |
| Rotor Speed - High | 905 rpm |
| Concave Area | 1829.1 in2 (1.2 m2) |
Separating
| Separator Type | rotary |
| Separating Area | 9191.6 in2 (6 m2) |
Cleaning System
| Total Cleaning Area | 10137.1 in2 (6.6 m2) |
| Cleaning Fan Speed - Low | 475 rpm |
| Cleaning Fan Speed - High | 900 rpm |
Grain Handling
| Grain Tank Capacity | 298 bu (10500 L) |
| Unloading Speed | 3.2 bu/sec (110 L/sec) |
