Salford CR9080 Elevation
Contents:
Dimensions
| Overall Length | 32.71 ft in (9970 mm) |
| Width Over Tires | 10.83 ft in (3300 mm) |
| Height To Top Of Isomount Cab | 13 ft in (3960 mm) |
Engine
| Engine Make | 2358 |
| Engine Model | Cursor 10 |
| Power | 489 hp (364.7 kw) |
| Power Boost Power | 530 hp (395.3 kw) |
| Power Measured @ | 2100 rpm |
Operational
| Operating Weight W/O Attachment | 34678.8 lb (15730 kg) |
| Fuel Capacity | 264.2 gal (1000 L) |
| Transmission Type | hydrostatic |
| Number Of Gears | 4 |
Threshing
| Rotor Diameter | 17.1 in (432 mm) |
| Rotor Length | 103.9 in (2638 mm) |
Separating
| Separating Area | 4743.1 in2 (3.1 m2) |
Cleaning System
| Total Cleaning Area | 10075.1 in2 (6.5 m2) |
| Cleaning Fan Speed - Low | 200 rpm |
| Cleaning Fan Speed - High | 1050 rpm |
Grain Handling
| Grain Tank Capacity | 298 bu (10500 L) |
| Unloading Speed | 3.2 bu/sec (110 L/sec) |
