Case IH Axial-Flow 2588
Contents:
Dimensions
| Width Over Tires | 11.01 ft in (3353 mm) |
| Wheelbase | 11.22 ft in (3418 mm) |
| Height To Top Of Isomount Cab | 12.91 ft in (3932 mm) |
Engine
| Engine Make | 2408 |
| Power | 305 hp (227.5 kw) |
| Power Boost Power | 325 hp (242.4 kw) |
| Displacement | 506 cu in (8.3 L) |
Operational
| Operating Weight W/O Attachment | 30000 lb (13607.8 kg) |
| Fuel Capacity | 180 gal (681.4 L) |
| Transmission Type | hydrostatic drive |
| Number Of Gears | 3 |
Threshing
| Rotor Diameter | 30 in (762 mm) |
| Rotor Speed - Low | 450 rpm |
| Rotor Speed - High | 1125 rpm |
Cleaning System
| Total Cleaning Area | 7905.1 in2 (5.1 m2) |
| Cleaning Fan Speed - Low | 450 rpm |
| Cleaning Fan Speed - High | 1250 rpm |
| Self Leveling? | No |
Grain Handling
| Grain Tank Capacity | 290 bu (10219.4 L) |
| Unloading Auger Length | 18 ft in (5.5 m) |
| Unloading Speed | 2.4 bu/sec (84.6 L/sec) |
