Zoomlion BG2100C
Browse All Zoomlion or Cold Planer Models
Contents:
Conveyor System
| Discharge Conveyor Width | 39.38 in (1000 mm) |
| Collecting Conveyor Width | 39.38 in (1000 mm) |
Dimensions
| Max Truck Clearance | 1.07 ft in (325 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | C16 |
| Gross Power | 630.3 hp (470 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 964.2 cu in (15.8 L) |
Operational
| Operating Weight - Full Load | 83334.8 lb (37800 kg) |
| Shipping Weight - Empty | 72311.7 lb (32800 kg) |
| Operating Speed | 98.5 ft/min (30 m/min) |
| Travel Speed | 2.8 mph (4.5 km/h) |
Rotary Cutter
| Cutting Width | 6.9 ft in (2100 mm) |
| Cutting Depth | 12.6 in (320 mm) |
| Cutter Diameter | 41.8 in (1060 mm) |
| Number Of Tools | 174 |
| Tool Spacing | 0.6 in (15 mm) |
Tracks
| Number Of Track Units | 4 |
| Front Track Length | 6.6 ft in (1995 mm) |
| Front Track Width | 12.1 in (305 mm) |
| Rear Track Length | 6.6 ft in (1995 mm) |
| Rear Track Width | 12.1 in (305 mm) |
