Dynapac PL350
Browse All Dynapac or Cold Planer Models
Contents:
Dimensions
| Front Axle Clearance | 24.41 in (620 mm) |
| Ground Clearance | 12.01 in (305 mm) |
| Overall Length | 116.34 in (2955 mm) |
| Overall Width | 3.32 ft in (1010 mm) |
| Wheelbase | 5.16 ft in (1570 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | Cummins |
| Engine Model | B 3.3 |
| Gross Power | 60.4 hp (45 kw) |
| Power Measured @ | 2200 rpm |
Operational
| Fuel Capacity | 33.1 gal (125 L) |
| Hydraulic System Fluid Capacity | 29.1 gal (110 L) |
| Water Spray System Fluid Capacity | 105.7 gal (400 L) |
| Operating Speed | 82.1 ft/min (25 m/min) |
| Travel Speed | 3.7 mph (5.8 km/h) |
Rotary Cutter
| Cutting Width | 1.2 ft in (350 mm) |
| Cutting Depth | 4 in (100 mm) |
| Cutter Diameter | 20.5 in (520 mm) |
| Number Of Tools | 38 |
| Tool Spacing | 0.5 in (12 mm) |
