UpRight AB60JRT
Contents:
Dimensions
| Overall Length | 29.2 in (8900 mm) |
| Overall Width | 7.88 ft in (2400 mm) |
| Overall Height - Mast Lowered | 8.21 ft in (2500 mm) |
| Ground Clearance | 11.82 in (300 mm) |
Platform
| Max Platform Height | 60.04 ft in (18300 mm) |
| Max Horizontal Reach | 42.98 ft in (13100 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
| Max Working Height | 66.61 ft in (20300 mm) |
| Platform Inner Length | 59.85 in (1520 mm) |
| Platform Inner Width | 29.93 in (760 mm) |
| Platform Rotation | 180 degrees |
Engine
| Engine Make | 2347 |
| Gross Power | 65 hp (48.5 kw) |
| Fuel Type | diesel |
Operational
| Operating Weight | 24799.8 lb (11249 kg) |
| Max Speed | 3 mph (4.8 km/h) |
| Tire Size | 15 x 19.5 |
| Tire Fill/Type | poly filled/lug |
