Snorkel TB42
Contents:
Dimensions
| Overall Length | 23.63 in (7200 mm) |
| Overall Width | 7.88 ft in (2400 mm) |
| Overall Height - Mast Lowered | 7.55 ft in (2300 mm) |
| Wheelbase | 7.88 ft in (2400 mm) |
| Ground Clearance | 9.85 in (250 mm) |
Platform
| Max Platform Height | 42 ft in (12800 mm) |
| Max Horizontal Reach | 33.14 ft in (10100 mm) |
| Max Working Height | 15.63 ft in (4763 mm) |
| Platform Inner Length | 59.85 in (1520 mm) |
| Platform Inner Width | 29.93 in (760 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
Engine
| Fuel Type | gas/diesel |
Operational
| Fuel Capacity | 20 gal (75.7 L) |
| Hydraulic System Fluid Capacity | 25 gal (94.6 L) |
| Max Speed | 3 mph (4.8 km/h) |
| Tire Size | 12x16.5 |
| Tire Fill/Type | pneumatic |
