Snorkel AB38N
Contents:
Dimensions
| Overall Length | 13.26 in (4040 mm) |
| Overall Width | 4.93 ft in (1500 mm) |
| Overall Height - Mast Lowered | 6.57 ft in (2000 mm) |
| Ground Clearance | 5.91 in (150 mm) |
| Turning Radius | 7.88 ft in (2400 mm) |
Platform
| Max Platform Height | 37.73 ft in (11500 mm) |
| Max Horizontal Reach | 20.02 ft in (6100 mm) |
| Max Working Height | 44.3 ft in (13500 mm) |
| Platform Inner Length | 47.25 in (1200 mm) |
| Platform Inner Width | 23.63 in (600 mm) |
| Max Platform Weight Capacity | 474 lb (215 kg) |
Engine
| System Voltage | 48 V |
| Number Of Batteries | 8.0000 |
| Battery Amp Hours | 220.0000 |
Operational
| Operating Weight | 8487.8 lb (3850 kg) |
| Max Speed | 2.5 mph (4 km/h) |
| Tire Fill/Type | non-marking |
