Haulotte HA46 RTJ PRO
Contents:
Dimensions
| Overall Length | 22.2 in (563.88 mm) |
| Overall Width | 7.7 ft in (2346.96 mm) |
| Wheelbase | 6.11 ft in (1862.33 mm) |
| Ground Clearance | 15 in (381 mm) |
| Gradeability | 40 % |
| Turning Radius - Outside | 14.9 ft in (4541.53 mm) |
| Transport Length | 16.7 ft in (5090.16 mm) |
| Transport Height- Maximum | 7.1 ft in (2.17 m) |
| Horizontal Reach | 27.3 ft in (8.33 m) |
| Tailswing Radius | 4 ft in (1219.2 mm) |
| Tilt Alarm | 5 degrees |
Platform
| Max Platform Height | 45.11 ft in (13749.53 mm) |
| Platform Inner Width | 34.5 in (876.3 mm) |
| Platform Inner Length | 95 in (2413 mm) |
| Overall Height (Stowed, Guardrail Folded) | 7.7 ft in (2.35 m) |
| Maximum No Of Persons | 2 |
| Max Working Height | 5.12 ft in (1557.53 mm) |
| Max Platform Weight Capacity | 500 lb (226.8 kg) |
Engine
| Engine Model | Kubota |
| Gross Power | 25 hp (18.7 kw) |
Operational
| Operating Weight | 1422 lb (645.1 kg) |
| Max Speed | 3.2 mph (5.2 km/h) |
| Tire Size | 850x340 |
| Tire Fill/Type | solid rough terrain |
Electrical
| Battery | 12V |
