Haulotte HA43 JE
Contents:
Dimensions
| Overall Length | 253.2 in (6431.28 mm) |
| Overall Width | 5 ft in (1524 mm) |
| Wheelbase | 6.7 ft in (2042.16 mm) |
| Ground Clearance | 6 in (152.4 mm) |
| Gradeability | 25 % |
| Turntable Rotation | 355 degrees |
| Overall Height | 6.11 ft in (1862.33 mm) |
| Turning Radius - Outside | 13 ft in (3962.4 mm) |
| Transport Height | 109.32 in (2776.73 mm) |
| Tilt Alarm | 3 degrees |
| Transport Length | 214.8 in (5455.92 mm) |
Platform
| Max Platform Height | 42.3 ft in (12893.04 mm) |
| Max Horizontal Reach | 28.5 ft in (8686.8 mm) |
| Platform Rotation | 180 degrees |
| Platform Inner Width | 32.4 in (822.96 mm) |
| Platform Inner Length | 46.8 in (1188.72 mm) |
| Jib Range Of Motion - Vertical | 130 degrees |
| Max Working Height | 48.3 ft in (14721.84 mm) |
| Max Platform Weight Capacity | 500 lb (226.8 kg) |
Engine
| System Voltage | 48 V |
| Battery Amp Hours | 345 |
Operational
| Operating Weight | 15942 lb (7231.2 kg) |
| Hydraulic System Fluid Capacity | 8 gal (30.3 L) |
| Max Speed | 2.8 mph (4.6 km/h) |
| Tire Size | 23x10-12 |
