Haulotte HA15IP
Contents:
Dimensions
| Overall Length | 21.66 in (6600 mm) |
| Overall Width | 4.93 ft in (1500 mm) |
| Overall Height - Mast Lowered | 6.57 ft in (2000 mm) |
| Wheelbase | 6.57 ft in (2000 mm) |
| Ground Clearance | 5.91 in (150 mm) |
| Turning Radius | 12.14 ft in (3700 mm) |
Platform
| Max Platform Height | 42.66 ft in (13000 mm) |
| Max Horizontal Reach | 27.73 ft in (8450 mm) |
| Platform Rotation | 180 degrees |
| Platform Inner Length | 47.25 in (1200 mm) |
| Max Platform Weight Capacity | 507.07 lb (230 kg) |
| Max Working Height | 49.22 ft in (15000 mm) |
| Platform Inner Width | 31.5 in (800 mm) |
Engine
| Engine Make | 0 |
| System Voltage | 48 V |
| Battery Amp Hours | 360.0000 |
| Charger Amps | 50 amps |
Operational
| Operating Weight | 16093.8 lb (7300 kg) |
| Hydraulic System Fluid Capacity | 13.3 gal (50 L) |
| Max Speed | 2.8 mph (4.5 km/h) |
| Tire Size | 23x10x12 |
| Tire Fill/Type | non marking |
