Genie Z45/25J Elec
Contents:
Dimensions
| Overall Length | 22.41 in (6830 mm) |
| Overall Width | 5.88 ft in (1790 mm) |
| Overall Height - Mast Lowered | 6.57 ft in (2000 mm) |
| Wheelbase | 6.67 ft in (2030 mm) |
| Ground Clearance | 9.45 in (240 mm) |
| Turning Radius | 13.98 ft in (4260 mm) |
Platform
| Max Platform Height | 45.67 ft in (13920 mm) |
| Max Horizontal Reach | 25.1 ft in (7650 mm) |
| Platform Rotation | 180 degrees |
| Platform Inner Length | 72.05 in (1830 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
| Max Working Height | 52.24 ft in (15920 mm) |
| Platform Inner Width | 29.93 in (760 mm) |
Engine
| Engine Make | 0 |
| System Voltage | 48 V |
| Number Of Batteries | 8 |
| Battery Amp Hours | 350 |
Operational
| Operating Weight | 16301 lb (7394 kg) |
| Fuel Capacity | 9.1 gal (34.1 L) |
| Hydraulic System Fluid Capacity | 8 gal (30.2 L) |
| Max Speed | 3 mph (4.8 km/h) |
| Tire Size | 9x14.5 |
| Tire Fill/Type | Foam |
