Massey Ferguson MF 190
Browse All Massey Ferguson or Baler Models
Contents:
Baler Pickup
| Overall Width | 8.11 ft in (2.48 m) |
| Number Of Bars | 5 |
| Number Of Tines | 120 |
| Tine To Tine Width | 6.96 ft in (2.12 m) |
| Lift Type | hydraulic cylinder |
Dimensions
| Overall Length | 29.2 ft in (8900 mm) |
| Overall Width | 10.47 ft in (3190 mm) |
| Overall Height | 12.08 ft in (3680 mm) |
| Tractor Pto Power Required | 120.7 hp (90 kw) |
| Weight | 18607.02 lb (8440 kg) |
Bale Size
| Bale Length - Min | 9 ft in (2740 mm) |
| Bale Height | 4 ft in (1200 mm) |
| Bale Width | 4.2 ft in (1280 mm) |
Feeding Chamber
| Packer Type | fork type, 6 tine |
Plunger
| Spm | 25.4 |
| Stroke Length | 780mm |
| Bearing Type | sealed taper roller & ball |
Wrapping System
| Twine Type | double knot, twine tie, polypropylene or sisal |
| Twine Ball Capacity | 24 |
| Wire Coil Capacity | 6 |
