Terex CR562RX
Browse All Terex or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 20.84 ft in (6350 mm) |
| Transport Width | 10.34 ft in (3150 mm) |
| Transport Height | 9.17 ft in (2794 mm) |
| Length Of Track On Ground | 10.67 ft in (3251 mm) |
| Track Width | 18 in (457 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSB5.9 |
| Gross Power | 240 hp (179 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | turbocharged |
Operational
| Operating Weight W/O Screed | 38915 lb (17651.6 kg) |
| Operating Weight W/ Screed | 46815 lb (21235 kg) |
| Fuel Capacity | 81.9 gal (310 L) |
| Hydraulic System Fluid Capacity | 75.1 gal (284 L) |
| Cooling System Fluid Capacity | 6.7 gal (25 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 105 amps |
Hopper/Paver
| Hopper Capacity | 9.9 lb (7.6 kg) |
| Paving Width - Std | 10.1 ft in (3050 mm) |
| Paving Width - Max | 29.9 ft in (9100 mm) |
| Paving Thickness - Max | 12.1 in (305 mm) |
| Paving Speed - Max | 131.3 ft/min (40 m/min) |
| Travel Speed - Max | 7.2 mph (11.5 km/h) |
| Auger Diameter | 16 in (406 mm) |
