Caterpillar BG225C
Browse All Caterpillar or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 18.42 ft in (5613 mm) |
| Transport Width | 8.61 ft in (2623 mm) |
| Transport Height | 8.61 ft in (2623 mm) |
| Length Of Track On Ground | 7.37 ft in (2244 mm) |
| Track Width | 14.02 in (356 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2236 |
| Engine Model | 3054DIT |
| Gross Power | 121 hp (90.3 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 244.1 cu in (4 L) |
Operational
| Operating Weight W/O Screed | 25992.6 lb (11790 kg) |
| Fuel Capacity | 60 gal (227 L) |
| Hydraulic System Fluid Capacity | 50 gal (189 L) |
| Cooling System Fluid Capacity | 8.4 gal (31.5 L) |
Hopper/Paver
| Hopper Capacity | 6.6 lb (5 kg) |
| Paving Width - Std | 6 ft in (1828 mm) |
| Paving Width - Max | 20 ft in (6096 mm) |
| Paving Speed - Max | 219.9 ft/min (67 m/min) |
| Travel Speed - Max | 5 mph (8 km/h) |
| Auger Diameter | 16 in (406 mm) |
