Komatsu HM350-1
Browse All Komatsu or Articulated Dump Truck Models
Contents:
Dimensions
| Overall Length | 36.18 ft in (11025 mm) |
| Overall Width | 11.32 ft in (3450 mm) |
| Overall Height | 12.14 ft in (3700 mm) |
| Wheelbase | 17.51 ft in (5335 mm) |
| Ground Clearance | 2.04 ft in (620 mm) |
| Dump Height | 23.4 ft in (7130 mm) |
| Dump Ground Clearance | 2.37 ft in (720 mm) |
Dump
| Capacity - Struck | 19.1 yd3 (14.6 m3) |
| Raise Time | 12 sec |
| Capacity - Heaped | 25.9 yd3 (19.8 m3) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | SAA6D140E-3 |
| Gross Power | 399.7 hp (298 kw) |
| Net Power | 388.9 hp (290 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 1438.4 lb ft (1950.2 Nm) |
| Aspiration | Turbocharged |
| Displacement | 930.1 cu in (15.3 L) |
Operational
| Fuel Capacity | 130.8 gal (495 L) |
| Hydraulic System Fluid Capacity | 47.6 gal (180 L) |
| Engine Oil Capacity | 13.8 gal (52 L) |
| Transmission Fluid Capacity | 30.4 gal (115 L) |
| Tire Size | 26.5 R25 |
Transmission
| Transmission Type | full-automatic |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
| Max Speed | 35.5 mph (57.1 km/h) |
Weights
| Center Axle - Empty | 13950.7 % |
| Front Axle - Empty | 34798.3 lb (15784.2 kg) |
| Rear Axle - Empty | 13950.7 lb (6327.9 kg) |
| Front Axle - Loaded | 40758.6 % |
| Center Axle - Loaded | 46657.8 % |
| Rear Axle - Loaded | 46657.8 lb (21163.7 kg) |
| Total Empty | 62699.5 lb (28440 kg) |
| Total Loaded | 134074.2 lb (60815 kg) |
