Terex AC500-2
Browse All Terex or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 52.5 ft in (16 m) |
| Max Height @ Max Raise Angle - No Jib | 193.57 ft in (59 m) |
| Min Working Radius | 9.85 ft in (3 m) |
| Max Working Radius | 170.61 ft in (52 m) |
| Max Elevating Angle | 83 degrees |
| Number Of Sections | 4 |
| Max Lift Capacity | 1102311.24 lb (500000 kg) |
| Swing Speed | 0.8 rpm |
Dimensions
| Transport Length | 63.29 ft in (19290 mm) |
| Transport Width | 9.85 ft in (3000 mm) |
| Transport Height | 13.13 ft in (4000 mm) |
| Width W/ Outriggers Extended | 31.5 ft in (9600 mm) |
| Carrier Length | 56.27 ft in (17150 mm) |
| Upper Structure Tail Swing Radius | 20.02 ft in (6100 mm) |
Upper Structure Engine
| Make | Terex |
| Model | OM 906 LA |
| Gross Power | 275 hp (205 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 811.4 lb ft (1100 Nm) |
| Torque Measured @ | 1600 rpm |
Carrier Engine
| Make | Terex |
| Model | OM 502 LA |
| Gross Power | 643.7 hp (480 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 2065.2 lb ft (2800 Nm) |
| Torque Measured @ | 1200 rpm |
Operational
| Operating Weight | 211643.8 lb (96000 kg) |
| Number Of Axels | 8 |
| Upper Structure Fuel Capacity | 79.3 gal (300 L) |
| Carrier Fuel Capacity | 155.9 gal (590 L) |
| Operating Voltage | 24 V |
| Tire Size | 14R25 |
Transmission
| Transmission Type | ZF-TC-Tronic automated |
| Max Speed - Forward | 39.8 mph (64 km/h) |
