Link-Belt ATC3130
Browse All Link-Belt or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 53.15 ft in (16.2 m) |
| Max Height @ Max Raise Angle - No Jib | 180.45 ft in (55 m) |
| Min Working Radius | 10 ft in (3.05 m) |
| Max Working Radius | 160 ft in (48.77 m) |
| Max Elevating Angle | 82 degrees |
| Max Lift Capacity | 260000 lb (117934.02 kg) |
| Swing Speed | 1.7 rpm |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 49.05 ft in (14950 mm) |
| Transport Width | 9.85 ft in (3000 mm) |
| Transport Height | 13.13 ft in (4000 mm) |
| Ground Clearance | 1.09 ft in (330 mm) |
| Width W/ Outriggers Extended | 24.61 ft in (7500 mm) |
| Carrier Length | 39.21 ft in (11950 mm) |
| Upper Structure Tail Swing Radius | 15.75 ft in (4800 mm) |
Upper Structure Engine
| Make | Link-Belt |
| Model | OM 904 LA |
| Gross Power | 173 hp (129.1 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 487 lb ft (660.3 Nm) |
| Torque Measured @ | 1200 rpm |
| Displacement | 259.4 cu in (4.3 L) |
Carrier Engine
| Make | Link-Belt |
| Model | OM 502 LA |
| Gross Power | 523 hp (390.1 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1770 lb ft (2399.8 Nm) |
| Torque Measured @ | 1300 rpm |
| Displacement | 972.1 cu in (16 L) |
Operational
| Operating Weight | 108233 lb (49093.7 kg) |
| Number Of Axels | 5 |
| Upper Structure Fuel Capacity | 84.6 gal (320 L) |
| Carrier Fuel Capacity | 132.1 gal (500 L) |
| Upper Structure Hydraulic System Fluid Capacity | 198.2 gal (750 L) |
| Carrier Hydraulic System Fluid Capacity | 76.7 gal (290 L) |
| Upper Structure Oil Capacity | 4.3 gal (16 L) |
| Carrier Oil Capacity | 10.6 gal (40 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 300 amps |
| Tire Size | 20.5R25 |
Transmission
| Transmission Type | automated manual transmission |
| Number Of Forward Gears | 16 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 52.9 mph (85 km/h) |
| Max Speed - Reverse | 4.4 mph (7 km/h) |
