Liebherr LTM1090/2
Browse All Liebherr or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 38.39 ft in (11.7 m) |
| Max Height @ Max Raise Angle - No Jib | 170.61 ft in (52 m) |
| Min Working Radius | 35.44 ft in (10.8 m) |
| Max Working Radius | 62.34 ft in (19 m) |
| Max Elevating Angle | 83.5 degrees |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 43.45 ft in (13241 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 12.9 ft in (3930 mm) |
| Ground Clearance | 1.25 ft in (380 mm) |
| Width W/ Outriggers Extended | 23.63 ft in (7200 mm) |
| Carrier Length | 34.26 ft in (10440 mm) |
| Upper Structure Tail Swing Radius | 16.56 ft in (5045 mm) |
Upper Structure Engine
| Number Of Cylinders | 4 |
| Make | Liebherr |
| Model | D 924 T-E |
| Gross Power | 161 hp (120 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 531.1 lb ft (720 Nm) |
| Torque Measured @ | 1200 rpm |
Carrier Engine
| Make | Liebherr |
| Model | D 9406 TI |
| Gross Power | 402.4 hp (300 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1253.9 lb ft (1700 Nm) |
| Torque Measured @ | 1500 rpm |
| Number Of Cylinders | 6 |
Operational
| Number Of Axels | 4 |
| Carrier Fuel Capacity | 79.3 gal (300 L) |
| Tires | 8 |
| Operating Voltage | 24 V |
| Tire Size | 14.00 R 25 |
Transmission
| Drive System | Axle 2 additionally driven |
| Transmission Type | Allison Automatic |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
Brakes
| Service Brake | Dual circuit , air servo brake |
