Grove AT880
Browse All Grove or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 40 ft in (12.2 m) |
| Max Height @ Max Raise Angle - No Jib | 96 ft in (29.27 m) |
| Min Working Radius | 10 ft in (3.05 m) |
| Max Working Radius | 110 ft in (33.53 m) |
| Max Elevating Angle | 80 degrees |
| Number Of Sections | 4 |
| Max Lift Capacity | 160000 lb (72574.79 kg) |
| Swing Speed | 1.9 rpm |
Dimensions
| Transport Length | 46.45 ft in (14155 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 12.64 ft in (3850 mm) |
| Width W/ Outriggers Extended | 22.31 ft in (6800 mm) |
| Upper Structure Tail Swing Radius | 13 ft in (3960 mm) |
Carrier Engine
| Make | Grove |
| Model | BF8L513 |
| Gross Power | 325.9 hp (243 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 863 lb ft (1170 Nm) |
| Torque Measured @ | 1500 rpm |
| Displacement | 781.2 cu in (12.8 L) |
Operational
| Operating Weight | 119049.7 lb (54000 kg) |
| Number Of Axels | 4 |
| Carrier Fuel Capacity | 96.5 gal (365 L) |
| Upper Structure Hydraulic System Fluid Capacity | 165.4 gal (626 L) |
| Operating Voltage | 24 V |
| Tire Size | 16.00x25 radials |
Transmission
| Transmission Type | powershift |
| Number Of Forward Gears | 12 |
| Number Of Reverse Gears | 6 |
| Max Speed - Forward | 43.5 mph (70 km/h) |
