Case IH ATX700 70ft
Contents:
| Transport Width | 17.68 ft in (5.39 m) |
| Transport Height | 13.5 ft in (4.12 m) |
| Inner Wing | 15 ft in (4.58 m) |
| Main Frame | 10 ft in (3.05 m) |
| Outer Wing | 15 ft in (4.58 m) |
| Base Width | 70 ft in (21.4 m) |
| Number Of Sections | 5 |
| Number Of Ranks | 4 |
| Rank To Rank Spacing | 26 in (66.1 cm) |
| Frame Depth | 108 in (274.4 cm) |
| Minimum Ground Clearance | 28 in (71.2 cm) |
| Caster To Packer Depth | 148 in (376 cm) |
| 10 In Spacing | 84 |
| 12 In Spacing | 70 |
| 10 In Spacing | 36500 lb (16556.2 kg) |
| 12 In Spacing | 34400 lb (15603.6 kg) |
| Main Frame Casters | 11Lx15 FI |
| Inner Wing Casters | 11Lx15 FI |
| Outer Wing Casters | 11Lx15 FI |
| Rear Transport Wheels | 11Lx15 FI |
